Controls and connections
The main controls and connections are located on the control box.
Controls and connections
|
1 |
Power button |
|
2 |
USB-C charging port |
|
3 |
SD card slot |
|
4 |
Rotary knob |
|
5 |
Antenna connector |
Cable connections on the device
|
Type of cable |
From |
To |
Purpose |
|---|---|---|---|
|
3-pin cable |
Control box |
Servo in the drop cap |
Controls the automatic release of the impact hammer during test procedures. |
|
4-pin cable |
Control box |
End of handle on the T-handle |
Passes test data from the accelerometer, in the impact hammer, to the control box. |
